The starter motor plug is spliced in so likely not standard.
Looks like this https://www.autosparks.co.uk/land-rover-defender-90-110-engine-wiring-harness-6
Looks like this https://www.autosparks.co.uk/land-rover-defender-90-110-engine-wiring-harness-6
Hicap phill
Well-Known Member
- Posts
- 15,764
- Location
- Wiltshire
Yep that looks the same loom.
From your starter does it go to a large solenoid ?
From your starter does it go to a large solenoid ?
doriz
Well-Known Member
- Posts
- 17,267
Nope. Wires trace back to the 8 pin plug.
Hicap phill
Well-Known Member
- Posts
- 15,764
- Location
- Wiltshire
So on the loom you removed did 2 large brown go from alternator plug to starter motor?
2 others from multi plug to starter motor? If so loom is fine.
2 others from multi plug to starter motor? If so loom is fine.
doriz
Well-Known Member
- Posts
- 17,267
I haven’t unravelled the tape yet (as I’m sick of being covered in oil) however, in essence yes. 4 big fat brown wires connect to starter, assume two of which loop to the alternator. In addition there are the engine temp, oil pressure and starter exciter wires. Plus a wire I cannot yet identify that was in the alternator portion of the harness.
Hicap phill
Well-Known Member
- Posts
- 15,764
- Location
- Wiltshire
Is that the exciter wire for the alternator ?
You should have
Oil pressure
Water temperature
Diesel live/coil live
Exciter wire
2x alternator
2x starter live
Solenoid
(Any other cables?)
doriz
Well-Known Member
- Posts
- 17,267
I’ll unpick it tomorrow and report back
