1989 90 Rebuild

Southernlandy · Jun 5, 2014

Thanks, 17 now

last exam is a week today so after that I'll be able to start driving lessons

and finish this off. Might start looking out for another project

Southernlandy · Jun 5, 2014

Engine mounts arrived today, and what a difference they make!

IamRobbie · Jun 5, 2014

yeh they actually line up mate! a lot better

Southernlandy · Jun 7, 2014

Just connected the battery and tried to turn the key- dead just the clicking relay. I hope this is just a flat battery and it's now on charge so I'll report back later, either with a video of it running or I won't report back because I'll be trying to solve the problem. Wish me luck.

Southernlandy · Jun 7, 2014

Got it started at last. Turns out it wasnt the flat battery but the earth for the starter solenoid relay wasn't connected. Too late to post the video tonight but there seems to be a major problem with the transfer box :/

trax · Jun 8, 2014

Southernlandy said:
Got it started at last. Turns out it wasnt the flat battery but the earth for the starter solenoid relay wasn't connected. Too late to post the video tonight but there seems to be a major problem with the transfer box :/

i found the dash earth.. it turns out is is in the same place as a 300,200,etc right of brake servo :doh:

missed it due to a load of paint

i thought your xfer and gearbox were new.. you did fill with oil didn't you

Southernlandy · Jun 9, 2014

Yes all the oil has been put in :/

Here's the video everyone.... https://www.youtube.com/watch?v=HgnFyFtTByw

Any ideas on the transfer box would be helpful. Is the noise due to the gears rattling as they are under no load from the propshafts?

jamesmartin · Jun 9, 2014

something is wrong there have you done anything to the box

Southernlandy · Jun 10, 2014

The gearbox was an ashcroft but the transfer box has been done by me. All the bearings have been changed, diff gears, crosspin, input gear and intermediate shaft. I followed the manual to the letter and took loads of pictures so I'm quite sure its all gone back together the way it came out.

jamesmartin · Jun 10, 2014

whats the number of t/box , there are 2 input gears that have 26 teeth

Southernlandy · Jun 10, 2014

It is a 22D and I ordered FTC5089 from Ashcroft

jamesmartin · Jun 10, 2014

22d d what b,c,d, did previous gear have no cross drilling and have less wide teeth

Southernlandy · Jun 10, 2014

22D******C I didn't compare them. The previous gear didn't have any crossdrilling

jamesmartin · Jun 10, 2014

if youve got the wrong input it will feel a little notchy as you turn box over, put it in diff lock g/box in neutral and turn hand brake drum

Southernlandy · Jun 10, 2014

Ok, I'll have another look tomorrow but it doesn't feel notchy at all?

jamesmartin · Jun 10, 2014

another common issue is putting a too long a bolt in the front g/box to t/box securing bolts, it catches intermediate gear or can do

Southernlandy · Jun 10, 2014

I think you have just saved me a whole load of pain. When putting the box on I wasn't sure about lengths of bolts so I'll try taking the bolt out at the bottom which I think should probably be a stud and try running it again

Southernlandy · Jun 16, 2014

All finished for exams!

Got a new jack, and what a difference it makes:

Spent most of today working on the tub until I had to go into college for a lesson:

Jonnygearbox · Jun 18, 2014

Love this thread keep up the good work

Southernlandy · Jun 21, 2014

More work on the tub, trying to stop the most of the corrosion. Not the best fix, but the easiest and hopefully effective.
