What fills this hole?

Hi folks, anyone able to identify this hole on my 59 series 2 gearbox? Can’t seem to locate it on the workshop manual. Any advice on the proper plug? It drives pretty well without being able to keep oil in it, but probably should be addressed

A bolt?

Couldn't resist

Shimsteriom said:

A bolt?

Couldn't resist

Click to expand...

Lol, trying to remember from my old series , was that for when u go wading to prevent water ingress on the plates then remove it after

been a long time since I had my series

fingers crossed I’ll get something right for a change

You’re right - it’s the flywheel drain hole. Plug is optional according to the manual I have. See attachment. I haven’t got one fitted and all’s been well for ever

TS2304 said:

View attachment 241321 You’re right - it’s the flywheel drain hole. Plug is optional according to the manual I have. See attachment. I haven’t got one fitted and all’s been well for ever

Click to expand...

Surely you are not saying you own a series, and the rear main does not leak?

lynall said:

Surely you are not saying you own a series, and the rear main does not leak?

Click to expand...

They only leak if you put oil in them

Yah I got something right , So what’s the prize, lol

land rovers don’t leak, they just mark there territory

gstuart said:

Yah I got something right , So what’s the prize, lol

Click to expand...

You get One Point...

gstuart said:

Lol, trying to remember from my old series , was that for when u go wading to prevent water ingress on the plates then remove it after

been a long time since I had my series

fingers crossed I’ll get something right for a change

Click to expand...

Amazing. Thanks so much!

TS2304 said:

View attachment 241321 You’re right - it’s the flywheel drain hole. Plug is optional according to the manual I have. See attachment. I haven’t got one fitted and all’s been well for ever

Click to expand...

Thank you!

TinCup said:

Amazing. Thanks so much!

Click to expand...

Ur so welcome

even more remarkable is I remembered that from over 20 x years ago , lol

Shimsteriom said:

You get One Point...

Click to expand...

sounds like the Eurovision Song Contest , at least I didn’t get Nul Points

Flywheel drain hole, you can get them from a plumbers merchant for pennies, cant remember the size though

I think it is 1/4" BSPT.
https://www.ebay.co.uk/itm/232606369920?hash=item36286b8880:g:0LIAAOSwyi9aPi2W
Engine would have had a bracket that the plug screwed into for storage when removed from housing have a a look in case it is there. in the same vicinity.

Blackburn said:

I think it is 1/4" BSPT.
https://www.ebay.co.uk/itm/232606369920?hash=item36286b8880:g:0LIAAOSwyi9aPi2W
Engine would have had a bracket that the plug screwed into for storage when removed from housing, have a a look in case it is there. in the same vicinity.

Click to expand...

On the side (drivers) of the bulkhead, there's a hole, you have to open the drivers' door to see it, the hole is for a spare plug, and it fits in the hole

Its actually a wading plug.....if you going in deep water....fit the plug.....keeps the water away from the clutch.....the bung is usualy screwed into a plate nearby.
