What engine oil

This site contains affiliate links for which LandyZone may be compensated if you make a purchase.

Stupot19

New Member
Posts
116
Location
Manchester
Hi all the old man has an l322 and is going to be doing a service next week what engine oil does he need
Its a 2004 td6

Many thanks
Stu

P.s i did a search but didnt find anything helpful thanks

Hi all the old man has an l322 and is going to be doing a service next week what engine oil does he need
Its a 2004 td6

Many thanks
Stu

P.s i did a search but didnt find anything helpful thanks

Look in Hand book - Rave

:scratching_chin:


Attachments

  • TD6Oil.jpg
    203.5 KB · Views: 230
From the Handbook....

Engine oil - Petrol vehicles
Use a 0W/30, 0W/40, 5W/30 or 5W/40, 5W/50 oil meeting specification
ACEA: A3 and B3 and having a viscosity band recommended for the temperature range of your locality.

Engine oil temperature ranges
0W/30 will protect from -22ºF (-30ºC) to 95ºF (35ºC).
0W/40 will protect from -22ºF (-30ºC) to 122ºF (50ºC).
5W/30 will protect from -22ºF (-30ºC) to 95ºF (35ºC).
5W/40 will protect from -22ºF (-30ºC) to 122ºF (50ºC).
10W/40 will protect from 14ºF (-10ºC) to 122ºF (50ºC).

Also from the handbook, but for the diesel

Engine oil - Td6
Use either a 5W/30, 5W/40, 5W/50 or 10W/40 oil,
meeting specifications ACEA - A3/B3; and having a
viscosity band recommended for the temperature
range of your locality.

Don't forget the gearbox oil and filter if you haven't already done it !

Slightly off engine oil topic, where do you get the correct spec oil for gearbox change?
Looking at changing mine soon and struggling to find it.

Cheers,
Rob

For the GM Box use only Texaco ETL-7045E oil or its direct equivalent (BMW p/n 83 22 0 026 922).

Use nothing else....some say use Dexron VI but the Legend RRPhil (Bemble) is not so sure - and considering he is a fecking autobox genius, I am not going to question his thoughts.....(quoted below)

Please excuse the slight deviation but it’s understandable that there’s a degree of confusion over the suitability of Dexron fluid in the ’02-’05 diesel Range Rover transmission. It is, after all, a GM Hydra-Matic transmission and Dexron is a registered trademark of General Motors and was specified by them for use in their Hydra-Matic transmissions.

For me the story gets even more complicated if we consider the ‘identical’ powertrain in the 2000-2003 BMW X5 i.e. M57 engine coupled to GM 5L40-E transmission :

The GM 5L40-E transmission has two BMW designations – one is the A5S360R (360Nm capacity) and the other is the higher rated A5S390R (390Nm capacity). These two transmissions use different fluids. The 360 uses Texaco ETL-7045E (BMW p/n 83 22 0 026 922) - i.e. the same fluid specified by LR for the Range Rover - and the 390 uses Texaco ETL-8072B (BMW p/n 83 22 0 024 359).

The BMW M57 engine in the early diesel Range Rover produces 390Nm maximum torque so you would expect it to have the uprated gearbox like the X5 does. However Land Rover specify ETL-7045E fluid – the one for the 360Nm transmission.

Just to add further to the confusion, on earlier BMW cars fitted with the same 5L40-E box the fluid specified was Dexron-III.

Apparently the ETL-8072B fluid for the 390 has now been superseded by Dexron-VI and Dexron-VI is designed to be backward compatible with earlier transmission hardware.

Confuses the heck out of me . I guess, having said all that, that it’s still wise to stick with the ETL-7045E fluid specified by Land Rover.
