series I,II,III, who wha????

nrgserv said:

2 or 2a?
know there was a difference with the headlight surround, but cant remember which way it was. these a raised from the grill with a bevel, the other type are inset.

Click to expand...

Spunka said:

Hope you don't mine old chap, But i,ve just saved that piture and set as my desktop background

Click to expand...

How can you tell the difference between Series 2s and early 2A's?

The easiest way is the chassis number as the Series 2 had a nine digit number that included the year of manufacture as the forth digit. Series 2 chassis numbers started with a 1. Series 2A chassis numbers start with a 2, and comprise of 8 digits.

141 0 02546 is a Series 2, 88” petrol, 1960 build, car number 2546.

241 02546a is a Series2A, 88” petrol, 2546th built since start of IIa production.

The Forward Control model was Land Rover’s answer to calls from customers wanting more payload . The prototype of this vehicle first ran in 1960 and was available as a Series 2A from September 1960. The Series 2A Forward Control had a 109” wheelbase, using 75% of the standard 109” chassis components. This vehicle was only available with the Rover’s four-cylinder petrol engine of 2286cc. The vehicle was under powered and unstable due to the combination of vehicle height and standard width axles.

To improve themodel the Rover engineers completely re-designed the vehicle, including options of Rover’s six-cylinder petrol engine of 2625cc, the length of which necessitated moving the front axle forward 1” increasing the wheelbase to 110”. This vehicle became the Series 2B was introduced in September 1966, other modifications including wider and stronger axles and stronger transmission.

Click to expand...

All the people normally associate with one or the other acutally changed before or after the 2A launch. for example, the flat apron and chrome ring headlamps are typcially considered Series 2 features, but they carried over into 2A production and were not replaced until 1963/1964. Likewise, the side horn push, dash mounted indicator switch, twist knob vent controls and screwed on vent flap hinges all typically associated with the Series 2 actually dissappeared in 1960/1961 almost a year before the 2A was launched.

Click to expand...

Bump said:

Taken from the Series 2 club page:



Also apparently change of engine to the 2.25 diesel...

- taken from s2cforum

Is this starting to get a bit too rivet county for the General Chat? Maybe the thread should be moved to the Series section so we can continue...

Click to expand...
