Thanks so much for this. Got my car yesterday and while fiddling about to learn what all the buttons did I managed to fold the mirrors in, but the passenger side one made that noise but did not move back. Definitely worth a try!
Folding mirror problem
- Thread starter topdog1456
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
Thanks so much for this. Got my car yesterday and while fiddling about to learn what all the buttons did I managed to fold the mirrors in, but the passenger side one made that noise but did not move back. Definitely worth a try!
Ok looking at this again I take it the pin is located between the motor and bottom motor cover so I need to take the motor away from the bottom cover to expose the area where the gearing is housed, is that correct:doh::frusty:
Hi
I have exactly the same problem. The windows fold in but 1 does not go out and comes in as your driving.
It seems loose. I have taken it apart but all the pins seem ok and nothing looks broken
Please help
Mr Noisy
Coming in your ears.
- Posts
- 10,146
- Location
- Altrincham, Cheshire
All the parts are on ebay these days, very easy to repair
Grayo
Active Member
- Posts
- 714
- Location
- Pontypridd, South Wales
Having replaced both my folding mirrors twice with the same problems I have now fitted the manual fold in/out mirrors. The adjustment of the mirror still works from inside on the control knob. Having spent around £500 in the past on replacement power fold units I purchased the last mirror from ebay for £65.
HTH
Grayo
HTH
Grayo
terr
Active Member
- Posts
- 319
- Location
- folkestone
hi all my os mirror is fine but the ns one makes no noise and docent try to move .
have tried folding it in and doing the switch,
any idears
j
have tried folding it in and doing the switch,
any idears
j
Grayo
Active Member
- Posts
- 714
- Location
- Pontypridd, South Wales
Possibly motor burnt out or wiring plug come apart ??? does if fold in if you do it manually ???
terr
Active Member
- Posts
- 319
- Location
- folkestone
its very loose but yes you can fold it back.
thanks j
Mr Noisy
Coming in your ears.
- Posts
- 10,146
- Location
- Altrincham, Cheshire
We have loads of freelanders in at work
If the mirror is faulty or in the wrong position it stops trying to work for a bit
And then a day or so later it will come back to life, even if the gears are broken it will still try
So sometimes it's worth just giving them a breather before you make any decisions
If the mirror is faulty or in the wrong position it stops trying to work for a bit
And then a day or so later it will come back to life, even if the gears are broken it will still try
So sometimes it's worth just giving them a breather before you make any decisions
Grayo
Active Member
- Posts
- 714
- Location
- Pontypridd, South Wales
I've never know any of mine to come back to life after a rest when they've
gone they've gone. I have tried repairing them as in the post above but to no avail. Sadly I've spent enough money on power fold replacements and now I'm on manual fold in/out at a fraction of the cost.
Mr Noisy
Coming in your ears.
- Posts
- 10,146
- Location
- Altrincham, Cheshire
Yeah just we've had a few that seem to get confused then give up then try again later
Pretty common thing if they get over worked and or get folded into the wrong position they seem to switch off
They're bloody fragile that's the problem so I don't blame you for going to manual fold
Pretty common thing if they get over worked and or get folded into the wrong position they seem to switch off
They're bloody fragile that's the problem so I don't blame you for going to manual fold
Just fixed my right side mirror.
Pin on motor housing was sheared as posted in this thread.
This is how I fixed it:
Drilled thru remainders of sheared pin in motor enclosure:
Cut a .255" piece from a longer 3/32" rolled pin:
Inserted in the base :
And fitted together.
Works great.
Pin on motor housing was sheared as posted in this thread.
This is how I fixed it:
Drilled thru remainders of sheared pin in motor enclosure:
Cut a .255" piece from a longer 3/32" rolled pin:
Inserted in the base :
And fitted together.
Works great.
P Draco
New Member
- Posts
- 4
- Location
- Clacton on sea essex
Hi peeps I just brought a 2004 freelander td4. My drivers side power mirror works fine now thanks to this tread, but the passenger side flaps in the wind literally. When I use the switch it makes all the right noises, but no movement. Any ideas?
Hippo
Lord Hippo
- Posts
- 53,698
I wonder if the gear has stripped it's teeth. Yer will need to take it apart and see wot has gone wrong. Electrical noises would make yer think the electrics is ok.
Last edited:
P Draco
New Member
- Posts
- 4
- Location
- Clacton on sea essex
Cheers will see if I can do it this weekend
Hi, I'm a new member. I have had this folding problem since I bought my Freelander 1 ten years ago. I have also had aproblem with a parasitic drain, Sometimes it can drain the battery overnight. Other times it is still OK after a fortnight. I have tried amny fixes to the mirrors themselves including disconnecting them. However, I think I have solved the problem. I suspected the mirror solenoid which is on the A pillar behind the glove box. I could head a strange clicking noise which when I checked was coming from the solenoid. When I investigated it it was warm even though the temperature outside was 4 deg. I replaced the solenoid ( It's a Ford so much cheaper than Landrover spare) Both mirrors now work perfectly at the first touch. I had already bought a n/s mirror believing that it was Faulty. Maybe it wasn't after all. The parasitic drain has now one away. Hopefully!!
