I agree that getting it completely leak free is a HUGE ask, but it’s not impossible. It does drip, and has left a small patch where it’s sat since the box went belly up. It hasn’t ran since Monday 5th, but still drips. That was part of the reason for wanting to do the seals.
Who’s rebuild an LT77 Suffix H?
- Thread starter mick 1986
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
I agree that getting it completely leak free is a HUGE ask, but it’s not impossible. It does drip, and has left a small patch where it’s sat since the box went belly up. It hasn’t ran since Monday 5th, but still drips. That was part of the reason for wanting to do the seals.
tottot
Well-Known Member
- Posts
- 8,001
- Location
- west wales coast
It is not getting the seal on to the crank with the guide that's the problem. The last one I had did not want to go into the flywheel housing. Others I have done have fitted fine. Just a hint/warning.
It is not getting the seal on to the crank with the guide that's the problem. The last one I had did not want to go into the flywheel housing. Others I have done have fitted fine. Just a hint/warning.
Much appreciated. Hopefully it won’t be a bugger, but I know how jobs like this can be. Maybe I should have bought 2 seals...?
Well it’s all back together. The gearbox doesn’t leak at all, it’s been sat waiting with oil in for 2 days and is completely dry, the same can’t be said for the transfer box. I need to have a look at the lower cover plate, but that’s a job for another week.
It’s a bit difficult getting into 1st, 2nd, and 3rd, but I have only tried it while stationary in the shed. There doesn’t appear to be any noises that signal a problem, from what I can hear over the engine. I have just pulled out of the shed, but I’m blocked in by the digger, so have to wait for that to be moved (I don’t have a key). Hopefully it all goes well and changes much easier when it’s moving. To say I’m a bit nervous is a HUGE understatement.
It’s a bit difficult getting into 1st, 2nd, and 3rd, but I have only tried it while stationary in the shed. There doesn’t appear to be any noises that signal a problem, from what I can hear over the engine. I have just pulled out of the shed, but I’m blocked in by the digger, so have to wait for that to be moved (I don’t have a key). Hopefully it all goes well and changes much easier when it’s moving. To say I’m a bit nervous is a HUGE understatement.
tottot
Well-Known Member
- Posts
- 8,001
- Location
- west wales coast
When I changed mine it took a good number of miles for the change to become free [ recon I was used to the sloppy old one as well ] changed the oil at 500mls. Good luck.
I have planned on trying to do 500miles this week, but not sure that’s going to happen. I will change the oil next week as that was also my plan. Thanks for the heads up though.
It drove home relatively well to be fair. There was a knocking noise coming from the box at initial startup, went when the clutch was dipped and didn’t come back. I have no idea what it was or what it could have been, but it’s made me really nervous about driving it. Gear changes are much better on the move, but not perfect. I’m guessing they will ease with time. No oil leaks from the box. It was stone cold to touch. Used all 5 gears, so time will tell. I will update after the first oil change.
Thanks to those who offered help and advise.
I have just returned from its first proper run out after the gearbox rebuild. For the most part it was ok. Gear changes are smooth, and not sloppy like with the old synchros. There is a small random knock that sounds, and feels, like it’s coming from the gearbox, it’s enough that my wife noticed it sat in the passenger seat. It seemed to only do it when pulling away, so may not be the gearbox, it could be a bush or something I haven’t tightened fully. I need to get it back in the shed and have another look. The gearbox has what I can only describe as “chatter”. It’s only when the clutch is released, and only when it’s in gear. I have no idea where it’s coming from or what it could be. Starting to think I should have scrapped this box and replaced it.
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
chatter can be normal with a new clutch fitted especially if heavy duty, did you use the 2 shortest bolts that secure t/box to g/box on rhs that go front to back
Yeah I’m quite sure I used the short bolts on the two through holes. I’m almost certain I did as I could turn the gearbox input shaft by hand and the transfer box output flanges both turned. I’m guessing if the wrong bolts were used, one of them would have bound up and stopped me turning it by hand?
The more I think about it, the more I think the bang was something not really related to the gearbox internals. I could be kidding myself though.....?
Edit: it is a heavy duty clutch, but it’s not new. I would guess it’s got 30-40K miles on it, but you could clearly see the matching marks on it still.
I have been out and checked the oil level. A dribble came out of the fill plug, so I can only assume it’s at the fill line (I did put 2.5l of oil in it when it was rebuilt). I emptied the boot of all the ****e I had used to do the gearbox, then went out for a run again. The bang that can be heard is definitely coming from the back end, possibly axle or bush related so for now that can be ignored. The gearbox “chatter” is worst in 3rd, it tends to fade away to an almost stop under throttle, but as soon as the throttle is backed off its back again. Short of removing the box and stripping it, I’m thinking of changing the oil and testing it again, but I don’t know what else to do?
@jamesmartin @tottot have either of you fitted the Ashcrofts oil pump to the LT77? I’m wondering if that’s what is chattering inside my gearbox? It makes sense when I think about it, sort of.
The main reasons for thinking it’s the pump are, it’s steel and not composite. The drive gear (pump) didn’t have the “dome” on the rear. The gears weren’t the exact same size and profile as original ones. I’m just thinking it could be “rattling” inside the oil pump housing and causing it.
The main reasons for thinking it’s the pump are, it’s steel and not composite. The drive gear (pump) didn’t have the “dome” on the rear. The gears weren’t the exact same size and profile as original ones. I’m just thinking it could be “rattling” inside the oil pump housing and causing it.
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
no i never fitted one, fibre pump isnt normally a weak part as such
I sat and pondered over which one to fit at that point too. Wish I just fitted the original one. I may strip it down and refit the original.
