tomseries3tom
New Member
- Posts
- 916
- Location
- birmingham
series 3 four wheel drive
- Thread starter tomseries3tom
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
Stumpy 1970
New Member
- Posts
- 143
What do you mean it won't go in. Is. It engaging and then jumping out. Will the selector not move. Need a bit more detail.
storm99
Spreading Joy & Harmony
- Posts
- 21,065
- Location
- Brexited. Living on an island.
Erm...have you changed the gearbox by any chance?
waldershelf
Well-Known Member
- Posts
- 2,397
- Location
- In the hills north west of Sheffield
Is it the original box or are you converting to permanent FWD and using the box that came with the engine.
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
does the red lever pull back into low and forward into hi properly ,does yellow knob push down ,theres a tin cover held on with 3 bolts which can be removed and ends of the two shafts lubricated and freed if stuck these shafts have so slide easily for selection to take place
tomseries3tom
New Member
- Posts
- 916
- Location
- birmingham
hi it is the original gear box with over drive, low range and overdrive works perfectly when u push the yellow knob down it just isnt engaging?
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
either i would think shafts arent sliding in output housing behind tin cover (which should be noticeable in that if yellow knob pushed down pulling red lever back and then forward should let yellow knob pop back up)or i would check to see if you have free wheeling hubs not locked for drive or a broken shaft or diff in axle ,you can check by jacking one wheel at a time and turning prop should turn in 2wd and lock in 4wd ,if prop doesnt turn or lock theres no drive between that wheel and transmission
markconnor33
New Member
- Posts
- 317
- Location
- Leeds
Confused
Can you pull the transfer box (red) lever towards the seatbox to engage low range.
Once in low range, is 4 WD engaged.
Is it just the low range lever that isn't doing much??
Are you sure it's not stuck in 4WD anyway in high range - mine was as the yellow lever wasn't held up by a spring when I first got it.
Mark
Can you pull the transfer box (red) lever towards the seatbox to engage low range.
Once in low range, is 4 WD engaged.
Is it just the low range lever that isn't doing much??
Are you sure it's not stuck in 4WD anyway in high range - mine was as the yellow lever wasn't held up by a spring when I first got it.
Mark
tomseries3tom
New Member
- Posts
- 916
- Location
- birmingham
Hi thanks for the replies after a lot of fault finding I figured out the
Freewheelin hubs were not engaged stupid me
Thanks for al the help
Freewheelin hubs were not engaged stupid me
Thanks for al the help
Land Raver
Well-Known Member
- Posts
- 2,015
- Location
- In the dog house
Result! - won't cost you anything in time and money
