Name the Gasket

RodneyA

Active Member

Posts

295

Location

Ayrshire, South West Scotland

• Jun 10, 2013

• #1

I've just noticed a couple of leaks coming from these areas So I suspect the seals are just needing changed but i'm not sure what seals they are.

First one is this.

The second one i'm not sure exactly where the leak is coming from but I've circled the area that's always wet.



UK_Landy

Member

Posts

67

Location

Rochester, Kent.

• Jun 10, 2013

• #2

Well picture number two are the fuel injection pipes. Or to be more precise the injection nozzles. There is an "O" ring under each nozzle that may be worth changing.

Picture one I can't quite make out but Landy Zone members are like buses. Wait a couple of minutes and another one will be along soon
.



jamesmartin

Well-Known Member

Posts

91,879

Location

louth lincs

• Jun 10, 2013

• #3

first one is gasket tkc1235l if its leaking you cant do much without stripping entire box unless its running down from above ,bottom pic ,top pipe is leak off and washers may need changing
