lcbandit's leaky lt77 and sloppy lt230

This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
lcbandit said:
Neil neil orange peel I've pmd ya :D:D
Click to expand...

oi, mandypandy :rolleyes:

for the benefit of the thread, the input gears been removed and tomorrow will be searching for another.

had I known earlier that it can be removed in situ, I'd have put the box back on.

if I cant find one tomorrow, it'll get put back together so it can be moved, and then swap it at a later date.

nrgserv said:
oi, mandypandy :rolleyes:

for the benefit of the thread, the input gears been removed and tomorrow will be searching for another.

had I known earlier that it can be removed in situ, I'd have put the box back on.

if I cant find one tomorrow, it'll get put back together so it can be moved, and then swap it at a later date.
Click to expand...

you'll have to count the teeth if you have a random one knocking about, some are 26 some are 28. For some reason my 300 box was running the old style gears but it was on a 96 vehicle. Just LR using what they found on the shelf

Dr_evil said:
you'll have to count the teeth if you have a random one knocking about, some are 26 some are 28. For some reason my 300 box was running the old style gears but it was on a 96 vehicle. Just LR using what they found on the shelf
Click to expand...

only 1.2 can be 28 or 26 tooth not 1.4,but earlier input frc5428 has 26 teeth too and is not compatible with later 26 tooth input, you can tell by serial number or tooth width

jamesmartin said:
only 1.2 can be 28 or 26 tooth not 1.4,but earlier input frc5428 has 26 teeth too and is not compatible with later 26 tooth input, you can tell by serial number or tooth width
Click to expand...

width of tooth, width of gap between teeth, pitch of teeth.
give me a specific place to measure from and to, an i'll go do it.

ftc5089 was fitted in both disco and defender till disco got to e suffix then disco went to 28 tooth ftc5087 def stayed with 26 tooth

Great read folks knowledge is power...very powerful thread....:praise:
I have missed some quality workshop hours hear by the looks Neil...
Great practice in preparation for the next box leak/removal wink wink nudge nudge :eek::eek:

AndyD90 said:
Great read folks knowledge is power...very powerful thread....:praise:
I have missed some quality workshop hours hear by the looks Neil...
Great practice in preparation for the next box leak/removal wink wink nudge nudge :eek::eek:
Click to expand...

its not power its just useful, and nrgserv must be a good mechanic :)

oi mandypandy :rolleyes:

gonna let us know if ya got home or leave us guessing ;)
verdict on vibrations?

:pop2:
AndyD90 said:
Great read folks knowledge is power...very powerful thread....:praise:
I have missed some quality workshop hours hear by the looks Neil...
Great practice in preparation for the next box leak/removal wink wink nudge nudge :eek::eek:
Click to expand...
every days a learning day, some go well, others well,.... I've had me fair share of hiccups.
jamesmartin said:
its not power its just useful, and nrgserv must be a good mechanic :)
Click to expand...

that sir from you, is one of the best compliments I've received in my line of work.
I thank you for posting :D
