right. discs arrived today, had a good read through Haynes and thought "****! i'm not sure i can do this!!":eek: its the later hub with the circlip. it goes on about 'half-shaft end-float specifications' i've done a search and others have just said tighten it up to seat the bearings, then back a bit.
im going to get a hub spanner and some locking compound tomorrow. i can probably do it but dont want to **** it up this close to the trip!
any tips or hints please?
if not i'll just have to live with it for now:confused:

front or back ? front just replace what shims you take off it really isnt that critical,disc bolts are 14mm bihex ,only hit disc never hub to remove disc ,hub will damage easily ,wheel bearings adjust first nut till tight back off till theres play adjust till all free play has just been eliminated ,then fit lock washer and tighten 2nd nut tight lock washer over both nuts adjacently

Bobdog said:
right. discs arrived today, had a good read through Haynes and thought "****! i'm not sure i can do this!!":eek: its the later hub with the circlip. it goes on about 'half-shaft end-float specifications' i've done a search and others have just said tighten it up to seat the bearings, then back a bit.
im going to get a hub spanner and some locking compound tomorrow. i can probably do it but dont want to **** it up this close to the trip!
any tips or hints please?
if not i'll just have to live with it for now:confused:
Click to expand...

Piece of cake, replace rear hub seal, pack with grease, tighten up first locknut, put steel spare wheel on hub so you can adjust freeplay with a wheel on, tighten second locknut......bear in mind that tightening second locknut will take up more tolerance so you may need to back off first locknut a little to allow for this, when happy bend over locktabs.
Screw a bolt into end of driveshaft to hold it in place while you put the circlip back on, you'll probably need only one shim ;)

BOOMER said:
Piece of cake, replace rear hub seal, pack with grease, tighten up first locknut, put steel spare wheel on hub so you can adjust freeplay with a wheel on, tighten second locknut......bear in mind that tightening second locknut will take up more tolerance so you may need to back off first locknut a little to allow for this, when happy bend over locktabs.
Screw a bolt into end of driveshaft to hold it in place while you put the circlip back on, you'll probably need only one shim ;)
Click to expand...

Well put its an art getting that first locknut just right ;)

jamesmartin said:
front or back ? front just replace what shims you take off it really isnt that critical,disc bolts are 14mm bihex ,only hit disc never hub to remove disc ,hub will damage easily ,wheel bearings adjust first nut till tight back off till theres play adjust till all free play has just been eliminated ,then fit lock washer and tighten 2nd nut tight lock washer over both nuts adjacently
Click to expand...

thanks james, i'll take the plunge (its front btw) i better get a bihex socket as well as i've only got hex and it probably won't fit (?) i'm also going to ring a local 4x4 parts supplier first, to see if they've got bearings in stock (in case they fall to bits!)

Bobdog said:
will do, ta mate:)

cheers chaps. though i will probably bottle out last minute and leave it til after the trip!:eek:
Click to expand...

If you can get it up to Camberley, I'm more than willing to give you a hand anyday this week. I did both front wheel bearings on mine last month.

Bobdog said:
thanks james, i'll take the plunge (its front btw) i better get a bihex socket as well as i've only got hex and it probably won't fit (?) i'm also going to ring a local 4x4 parts supplier first, to see if they've got bearings in stock (in case they fall to bits!)
Click to expand...


I can pop around if you like I got a bearing race seater you can borrow, and ill show how its done :) I'm in Horsham pm me if needed

Last edited:
*minty* said:
im comin down south tomoro guys :cheer2:..... brace yourselves :D
Click to expand...

:p:D

Last edited:
