Fuel gauge and warning light .

davidsw

Member

Posts

20

Location

Oxford

• Aug 22, 2020

• #1

Good day

I have a defender 1990 diesel 200 tdi (2 wire sender ) . The float works with a variable resistance I’ve got my wires mixed up on the instrument panel . Can some help please colours or a diagram .
Thanks . 18 months I’m nearly there



Attachments

•

  65.5 KB · Views: 98

mystery

Well-Known Member

Posts

1,509

Location

BULKINGTON

• Aug 23, 2020

• #2



davidsw

Member

Posts

20

Location

Oxford

• Aug 23, 2020

• #3

Thanks . Got it . The variable earth had voltage on it ........ . Not good for a fuel tank lol few
