Which is the best crankshaft rear oil seal to use and is it fitted flush to the front or to the back thanks
Discovery 200tdi
- Thread starter Coopers100
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
I personally would use an OEM like Cortico, it’s a lot of work taking out the box to replace a dodgy pattern part,
The original seal was EER1535 superseded to EER2532,
https://www.turnerengineering.co.uk/err-2532-rear-oil-seal-c2x21124150
The original seal was EER1535 superseded to EER2532,
https://www.turnerengineering.co.uk/err-2532-rear-oil-seal-c2x21124150
Use quality seal, about 15/20 quid Iirc
Apply a thin smear of loctite to the outside of the seal housing
Do not grease the seal face/crank land or it will leak
I fitted mine with a blunt soft drift and a hammer
Iirc flush with the front of the housing, but pls confim before hand, as like said above its a ton of work for a silly seal!
Seal comes with install sleeve to protect seal face from damage on crankshaft
ERR2532G
Apply a thin smear of loctite to the outside of the seal housing
Do not grease the seal face/crank land or it will leak
I fitted mine with a blunt soft drift and a hammer
Iirc flush with the front of the housing, but pls confim before hand, as like said above its a ton of work for a silly seal!
Seal comes with install sleeve to protect seal face from damage on crankshaft
ERR2532G
