A couple of questions if you could help please

This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
min200

min200

Active Member
Posts
918
Location
Nottingham
Right then the saving for my Landy project has been going well :) and I am going to go and have a look at an exmilitary 24 volt lwb series 3 over the weekend but there are a couple of things im not sure about and I was hoping you good folks might help!

It's unregistered and the chap doesn't have the military release papers so where abouts will I find the vin plate so I could get the history of the vehicle?

Are 24 volt motors ok to use or would it be more trouble than its worth? (I drive artics for a living so have a rough idea but is it different/more trouble on an older car?)

It has some sort of built in extra piping and heater between the seats (will get a pic as soon as I look at it) any ideas what that could be for on a military vehicle?

Any other advice before I plunge in and have a look?

The chap is looking in the region of £500 but I wont be paying that lol it really will need some work doing to it but it was a project I wanted so I could build from the ground up!

Thanks in advance folks and have a great Easter.

24 volt spares (alternators/starter/relays/bulbs etc) will be harder to get hold of (+ more expensive), extra pipes are part of the artic heater kit and could be removed.

Thanks folks.

Where would the vin plate be located?

Im going to have a look at it on Monday so would like to appear to know what I am doing!

min200 said:
Thanks folks.

Where would the vin plate be located?

Im going to have a look at it on Monday so would like to appear to know what I am doing!
Click to expand...


HOME PAGE


IDENTIFICATION NUMBERS (CHASSIS)


© Copyright seriesdiesellandrover.com 2013 All rights reserved

JOBS COMPLETED

HANDBRAKE

PROPSHAFT

ENGINE

STEERING

DIVIDER

FUEL TANK

GEAR STICK

FOOT BRAKE

SWIVEL HOUSING

LAND ROVER INFO

GEAR LEVERS

ENGINE TIMING

ELECTRICAL SYSTEM

LUBRICANTS

TOOLS/EQUIPMENT

VISITORS VEHICLES

VALVE CLEARANCES

EXHAUST SMOKE

GLOWPLUGS

The Series 3 Land Rover has many Identification numbers stamped about the vehicle. Although these aren’t really required when ordering parts it is important to know what components are fitted to your vehicle in case they have been changed at some point in its life. For example if you wanted a front inner hub bearing for your 1975 Series 3 but someone in the past had exchanged the front axle from one off a 1971 model then you might end up with the incorrect part as the bearing changed spec in 1972!

to the bulkhead inside the engine bay. Don’t be alarmed if the plate reads BL Cars as these were used up to approximately 1981. The number was also stamped into the right hand side chassis rail just behind the front bumper, and above the spring hanger. If your chassis has been replaced then the old number ‘SHOULD’ have been stamped into the replacement. Many have not however. That said, if your number has been covered with layers of paint and under seal etc then it may be difficult to locate even if the chassis is original.

The VIN plate(or vehicle Identification number) and chassis number plate on a Series 3 can be found in two places. Pre 1979 models were classed as having a chassis number and had the plate fixed to the bulkhead inside the cab by screws just above the gearbox cover. From 1979 vehicles were classed as having a VIN number and a different type of plate was riveted

CHASSIS NUMBER SEQUENCES 1971-1975

(88 INCH UTILITIES)

901-00001A TO 901-11900A Petrol (4 cylinder) Home Market

902-00001A TO 902-02640A Petrol (4 cylinder) RHD Export

903-00001A TO 903-06249A Petrol (4 cylinder) RHD CKD

904-00001A TO 904-09283A Petrol (4 cylinder) LHD

905-00001A TO 905-04541A Petrol (4 cylinder) LHD CKD

906-00001A TO 906-07270A Diesel Home Market

907-00001A TO 907-00964A Diesel RHD Export

908-00001A TO 908-01002A Diesel RHD CKD

909-00001A TO 909-02807A Diesel LHD

910-00001A TO 910-05196A Diesel LHD CKD

921-00001A TO 921-00757A Petrol (4 cylinders) Home Market

922-00001A TO 922-00894A Petrol (4 cylinders) RHD Export

923-00001A TO 923-00198A Petrol (4 cylinders) RHD CKD

924-00001A TO 924-04050A Petrol (4 cylinders) LHD

925-00001A TO 925-07572A Petrol (4 cylinders) LHD CKD

926-00001A TO 926-00046A Diesel Home Market

927-00001A TO 927-00148A Diesel RHD Export

928-00001A TO 928-99921A Diesel RHD CKD

929-00001A TO 929-01200A Diesel LHD

930-00001A TO 930-01110A Diesel LHD CKD

(88 INCH STATION WAGONS)

895-00001A TO 895-01909A Diesel LHD Export

951-00001A TO 951-05805A Petrol (4 cylinder) Home Market

952-00001A TO 952-00102A Petrol (4 cylinder) RHD Export

953 Series (none built)

954-00001A TO 954-04518A Petrol (4 cylinder) LHD

955 Series (none built)

(These numbers were used from 1971 to 1979)

(88 INCH LIGHTWEIGHT)

911-00001A TO 911-07289C Petrol (4 cylinder) Home Market

912-00001A TO 912-05039C Petrol (4 cylinder) RHD Export

913-00001A TO 913-15018C Petrol (4 cylinder) RHD CKD

914-00001A TO 914-16091C Petrol (4 cylinder) LHD

915-00001A TO 915-03990C Petrol (4 cylinder) LHD CKD

916-00001A TO 916-95070C Diesel Home Market

917-00001A TO 917-02026C Diesel RHD Export

918-00001A TO 918-03492C Diesel RHD CKD

919-00001A TO 919-02991C Diesel LHD

920-00001A TO 920-02562C Diesel LHD CKD

941-00001A TO 941-02122C Petrol (6 cylinder) Home Market

942-00001A TO 942-00486C Petrol (6 cylinder) RHD Export

943-00001A TO 943-03120C Petrol (6 cylinder) RHD CKD

944-00001A TO 944-01761C Petrol (6 cylinder) LHD

945-00001A TO 945-02076C Petrol (6 cylinder) LHD CKD

(109 INCH UTILITIES)

931-00001A TO 931-01848C Petrol (4 cylinder) Home Market

932-00001A TO 932-02232C Petrol (4 cylinder) RHD Export

933-00001A TO 933-03174C Petrol (4 cylinder) RHD CKD

934-00001A TO 934-08752C Petrol (4 cylinder) LHD

935-00001A TO 935-00852C Petrol (4 cylinder) LHD CKD

936-00001A TO 936-00782C Diesel Home Market

937-00001A TO 937-00488C Diesel RHD Export

938-00001A TO 938-00300C Diesel RHD CKD

939-00001A TO 939-02163C Diesel LHD

940-00001A TO 940-00378C Diesel LHD CKD

946-00001A TO 946-01378C Petrol (6 cylinder) Home Market

947-00001A TO 947-00693C Petrol (6 cylinder) RHD Export

948-00001A TO 948-00732C Petrol (6 cylinder) RHD CKD

949-00001A TO 949-01785C Petrol (6 cylinder) LHD

950-00001A TO 950-00042C Petrol (6 cylinder) LHD CKD

(109 INCH STATION WAGONS)

266-00001A TO 266-00238C Petrol (6 cylinder) Home Market

267-00001A TO 267-00064C Petrol (6 cylinder) RHD Export

269-00001A TO 269-00148C Petrol (6 cylinder) LHD

(These numbers were used from 1971 to 1977 when production ceased)

(109 INCH ‘ONE TON’


CHASSIS NUMBER SEQUENCES 1975-1979

4 CYLINDER PETROL MODELS

Prefix Codes 901, 902, 903, 904, 905 (For Utilities)

Prefix Codes 921, 922, 923, 924, 925 (For Station Wagons)

Serial number sequence began at 12500A until 57435A



4 CYLINDER DIESEL MODELS

Prefix Codes 906, 907, 908, 909, 910 (For Utilities)

Prefix Codes 926, 927, 928, 929, 930 (For Station Wagons)

Serial number sequence began at 08000A until 29522X

(88 INCH MODELS)

(109 INCH MODELS)

4 CYLINDER PETROL MODELS

Prefix Codes 911, 912, 913, 914, 915 (For Utilities)

Prefix Codes 931, 932, 933, 934, 935 (For Station Wagons)

Serial number sequence began at 16000C until 99999C

From approx Jan 1979 00001D until 16127D



4 CYLINDER DIESEL MODELS

Prefix Codes 916, 917, 918, 919, 920 (For Utilities)

Prefix Codes 936, 937, 938, 939, 940 (For Station Wagons)

Serial number sequence began at 06000C until 34641X



6 CYLINDER PETROL MODELS

Prefix Codes 941, 942, 943, 944, 945 (For Utilities)

Prefix Codes 946, 947, 948, 949, 950 (For Station Wagons)

Serial number sequence began at 12000C until 28641C


VIN NUMBER SEQUENCES 1979-1985

VIN PLATE EXAMPLE: SA L LB A A G 1 A A 123456 (SALLBAAG1AA123456)

British Leyland (not used 1979-1980)


Land Rover (not used 1979-1980)


Series III


A=88 inch

B=88 inch Lightweight

C=109 inch

D=109 inch One Ton


A=Truck cab, Hard top or Soft top.

B=3 Door Station Wagon (88”)

H=HCPU

M=5 Door Station Wagon (109”)


G= 4 CYLINDER DIESEL 2.25 LITRE OR 2.3 LITRE

H=4 CYLINDER PETROL 2.25 LITRE OR 2.3 LITRE

K=6 CYLINDER DIESEL 3.4 LITRE (SPANISH ONLY)

P=6 CYLINDER PETROL 2.6 LITRE

R=6 CYLINDER PETROL 2.6 LITRE (SOUTH AFRICA)

S=6 CYLINDER DIESEL 3.4 LITRE (SPANISH ONLY)

T=6 CYLINDER PETROL 3.4 LITRE (SPANISH ONLY)

V=V8 PETROL 3.5 LITRE

X=4 CYLINDER PERKINS DIESEL 3.8 LITRE (SOUTH AFRICA)

Z=4 CYLINDER ISUZU DIESEL 3.9 LITRE (AUSTRALIA ONLY)




1=RHD 4 Speed Manual

2=LHD 4 Speed Manual

5=RHD 4 Speed Manual and Overdrive

6=LHD 4 Speed Manual and Overdrive


88 inch or 109 inch


A=Assembled at Solihull (UK)

F=Assembled Overseas from CKD


Serial Number


A Suffix used on all models until approx September 1972

B Suffix used on all models from approx September 1972 to approx August 1974

C Suffix used on all models from approx August 1974 until the change over to VINs in 1979

D Suffix used on 2.25 Petrol models only from January 1979 after all numbers in the original sequence had been used: Serial numbers returned to 000001. D Suffix production ended when the VIN system was introduced in October 1979.

NOTE:

1971-1975 1975-1979 1979-1985

BACK TO TOP

BACK TO TOP

BACK TO TOP

CHASSIS ENGINE GEARBOX FRONT AXLE BACK AXLE

CHA

Not meaning to sound funny (but can be quite easily if required) but, do you know owt about series landys?

I wouldn't buy a "tank" much as I'd like to and then go on a tank forum and ask why there isn't a name badge on the boot, what the big snorkel sticking out of the front of the castley bit is and if 48V electrics are any good. ;)

bushwwacker said:
Not meaning to sound funny (but can be quite easily if required) but, do you know owt about series landys?

I wouldn't buy a "tank" much as I'd like to and then go on a tank forum and ask why there isn't a name badge on the boot, what the big snorkel sticking out of the front of the castley bit is and if 48V electrics are any good. ;)
Click to expand...

I don't care about the vehicle I just want sommink wiv a castley bit :)

OH I do apologise I didn't see the entry requirements to the forum. Which qualifications would you prefer?

I thought the point of forums was to help build up communities of like minded folk whether they are new to the "scene" or not.

If you don't want to advise or be helpful in any way why take the time to respond with snide comments? Im certainly not going to give you a list of what my qualifications are or are not in the motoring world and even if I were to I don't have the address of the bridge you live under.

Thank you again to the folks that took the time to comment with the helpful information it is much appreciated.

min200 said:
OH I do apologise I didn't see the entry requirements to the forum. Which qualifications would you prefer?

I thought the point of forums was to help build up communities of like minded folk whether they are new to the "scene" or not.

If you don't want to advise or be helpful in any way why take the time to respond with snide comments? Im certainly not going to give you a list of what my qualifications are or are not in the motoring world and even if I were to I don't have the address of the bridge you live under.

Thank you again to the folks that took the time to comment with the helpful information it is much appreciated.
Click to expand...

ERRRR???
Well excuse us your excellency for adding some light hearted banter that isnt aimed at humiliation or any other way of spoiling your "scene"
If you check the forum there will always be some banter but we all want to help if we can, and in fact we do OFTEN :confused:

min200 said:
OH I do apologise I didn't see the entry requirements to the forum. Which qualifications would you prefer?

I thought the point of forums was to help build up communities of like minded folk whether they are new to the "scene" or not.

If you don't want to advise or be helpful in any way why take the time to respond with snide comments? Im certainly not going to give you a list of what my qualifications are or are not in the motoring world and even if I were to I don't have the address of the bridge you live under.

Thank you again to the folks that took the time to comment with the helpful information it is much appreciated.
Click to expand...


Are you serious? :confused:

Did that spill out naturally or did you have to work up to it? :rolleyes:

You've had some quality help and the opportunity to have a giggle...all for nothing, nada, free of charge.

No problem, you're welcome...
