I am interested in the "no smoke" design. How's that meant to work? And does it actually work?

I am interested in the "no smoke" design. How's that meant to work? And does it actually work?

Secondary combustion, it's what the upper chamber with its own separate air supply is for.

Not exactly smokeless but much reduced smoke and far better efficiency.

I am interested in the "no smoke" design. How's that meant to work? And does it actually work?
Mine aint proven yet and it may have shortcomings. Primary air on a modern stove comes from 'above' the door. It flows downward over the glass (keeps it clean) then under the fuel and feeds the fire. This burns away nicely but within a few inches of rising towards the flue, all the oxygen is used up and whats left along with a pile of unburnt fuel (smoke) exits the chimley.
If you can introduce more air at the top of the fire, the smoke re ignites and a secondary burn takes place at the top of the fire.

This process's efficiency depends on a few things. The baffle above the flames should slope so that the rear of the fire ceiling is higher than the exit. This creates two temperatures of smoke. The cooler smoke swirls round the higher end until reburnt whenst it gets a bit otter and finally exits. The air feeding the secondary burn jets should be super heated on its way to the jets. Some of the secondary burn should take place in the secondary burn chamber as the ignited smoke exits the main fire on its way to the flue.

Im sure the manufacturers spend years perfecting the flow and temps and whatnot. Me on the other hand wing it quite a bit and suck it and see.
Its the way I roll MF. ;)

At the end of the day it will get hot. If I can see a second burn taking place at the top its got to be more efficient and less smokey. If I can see flames lapping round the rim of the top chamber I will be a happy boy and @Nig may get his sausage :cool:

  • Like
Reactions: Nig
This chap had good results with a very simple ammo box design. You can see by the smoke or lack of it, its quite efficient.


  • Like
Reactions: Nig
Mine aint proven yet and it may have shortcomings. Primary air on a modern stove comes from 'above' the door. It flows downward over the glass (keeps it clean) then under the fuel and feeds the fire. This burns away nicely but within a few inches of rising towards the flue, all the oxygen is used up and whats left along with a pile of unburnt fuel (smoke) exits the chimley.
If you can introduce more air at the top of the fire, the smoke re ignites and a secondary burn takes place at the top of the fire.

This process's efficiency depends on a few things. The baffle above the flames should slope so that the rear of the fire ceiling is higher than the exit. This creates two temperatures of smoke. The cooler smoke swirls round the higher end until reburnt whenst it gets a bit otter and finally exits. The air feeding the secondary burn jets should be super heated on its way to the jets. Some of the secondary burn should take place in the secondary burn chamber as the ignited smoke exits the main fire on its way to the flue.

Im sure the manufacturers spend years perfecting the flow and temps and whatnot. Me on the other hand wing it quite a bit and suck it and see.
Its the way I roll MF. ;)

At the end of the day it will get hot. If I can see a second burn taking place at the top its got to be more efficient and less smokey. If I can see flames lapping round the rim of the top chamber I will be a happy boy and @Nig may get his sausage :cool:


Cocktail or knockwurst ?

I suspect the trick is getting the secondary air feed hot enough. Looking forwards to seeing how well it works :)

I've wondered about making a vented double skinned angled throat plate with holes just under the leading edge.

I reckon that'd get nicely warm but it'd be a right faff to make in a circular burner.

I suspect the trick is getting the secondary air feed hot enough. Looking forwards to seeing how well it works :)

I've wondered about making a vented double skinned angled throat plate with holes just under the leading edge.

I reckon that'd get nicely warm but it'd be a right faff to make in a circular burner.
I think flow is the key. As you dont need a massive amount at the jets it makes sense to have a larger than needed delivery chamber. this should keep the flow rate down and give it time to heat.

Saveloy. Big boy. :p
I suspect the trick is getting the secondary air feed hot enough. Looking forwards to seeing how well it works :)

I've wondered about making a vented double skinned angled throat plate with holes just under the leading edge.

I reckon that'd get nicely warm but it'd be a right faff to make in a circular burner.


Sounds like a mouthful :eek:

Im sure the manufacturers spend years perfecting the flow and temps and whatnot. Me on the other hand wing it quite a bit and suck it and see.
Its the way I roll MF. ;)

I am sure the manufacturers spend years perfecting their sales literature. But TBH I haven't seen it makes a lot of difference in practice.

I have had a few stoves, ancient and modern, cheap and expensive. And my MO was always the same, light it up, all dampers except the bottom shut, get a good fire going, and then shut the bottom damper down as well, and wait until the heat goes off, then refuel.

Wouldn't surprise me if yours is as good as theirs when finished. At the end of the day, it is a metal box with burning wood in it.

I always found the business about airwash keeping the glass clean was rubbish as well.
The glass always gets a bit black. Best way to clean it off is to spit on a rag, pick up a bit of wood ash, and wipe the black away with that.
