Swb series 3 radiator panel

wwwfc666

Active Member

Posts

170

Location

Northants

• Apr 2, 2018

• #1

just about to put the new radiator panel etc on the chassis.
Looking for a bit of guidance on whether I can bolt it all down now tight , bearing in mind the wings tub etc are not on yet.
I see it should have rubber spacers to help alignment and vibration I guess.
I was just going to cut these spacers out of a bit of rubber, as they were missing.
Any idea how many needed if I cut out of 2mm rubber?



R

rob1miles

Well-Known Member

Posts

3,565

Location

Slough and Bath

• Apr 2, 2018

• #2

I would leave it a bit loose and work forwards from the bulkhead so you don't built in too much stress. Probably not a huge issue as the holes are all clearance.



wwwfc666

Active Member

Posts

170

Location

Northants

• Apr 2, 2018

• #3

Nice one thanks rob



J

John S

Well-Known Member

Posts

3,288

Location

Kinross

• Apr 3, 2018

• #4

X1. Leave it loose. Proper alignment of the bulkhead to the tub and doors is dependent on the alignment of the bulkhead to the wings and radiator plate. If it’s left loose for now you can fettle it all true and tighten once everything is lined up.



tottot

Well-Known Member

Posts

8,150

Location

west wales coast

• Apr 3, 2018

• #5

6 spacers the originals were quit thin. 2 each.



Last edited: Apr 3, 2018

Rubins4

Well-Known Member

Posts

813

• Apr 3, 2018

• #6

Agreed, no need to bolt down tight now, and you might needs some slack for alignment later.

The original rubber pads were about 50mm square by about 2mm. Only had 1 under each bolt along the bottom, @tottot where did the other three come from??
