S2 flat front valance holes

wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 22, 2014

• #1

Could anyone tell me if this panel had three holes drilled in it just in front of the grill panel, or has someone done this after. mine has them and I can't see the point of them as there is nothing to bolt on to underneath.



blue beasty

Leaks an prone to bits dropping off

Posts

63,684

Location

Gloucestercotshirewolds

• Mar 22, 2014

• #2

Should be no holes in the face



wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 22, 2014

• #3

blue beasty said:

Should be no holes in the face

Click to expand...

thats what i thought, thanks.



W

Webley1991

Well-Known Member

Posts

2,579

Location

London

• Mar 22, 2014

• #4

I repaired my panel by sticking some thin aluminium plate over the holes on the back of the panel with araldite. They can then be filled on the visible side using body filler and smoothed off. Once painted you would never know they were there.

Even better, if you know someone who can TIG weld aluminium, they could properly fill the holes in.



wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 22, 2014

• #5

Webley1991 said:

I repaired my panel by sticking some thin aluminium plate over the holes on the back of the panel with araldite. They can then be filled on the visible side using body filler and smoothed off. Once painted you would never know they were there.

Even better, if you know someone who can TIG weld aluminium, they could properly fill the holes in.

Click to expand...

Im going to glass fibre back off holes and fill, already done this on the dash panel that had unwanted holes drilled in.



wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 23, 2014

• #6

Just found this picture on S2C website this S2 seems to have brackets where my valance has holes any thoughts on this BB. Login



blue beasty

Leaks an prone to bits dropping off

Posts

63,684

Location

Gloucestercotshirewolds

• Mar 23, 2014

• #7

Can't see without logging in and I'm a little bit banned from there



blue beasty

Leaks an prone to bits dropping off

Posts

63,684

Location

Gloucestercotshirewolds

• Mar 23, 2014

• #8

If you're talking about these holes...

They're for these brackets..

Sorry for any confusion I'd assumed (stupidly) you were talking about other holes cause without the brackets there's nothing to hold the apron except two tiny screws at the front



wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 23, 2014

• #9

As you can see from the pictures I don't have any brackets, but it looks like something has been cut off the front crossmember ( bit big for valance bracket? ) and the valance has three holes.



samc88

Drivels spiritual representative

Posts

2,838

Location

Anglesey, North Wales

• Mar 23, 2014

• #10

The brackets BB showed share the same bolts as what bolt the front panel to the chassis



wickford90

Well-Known Member

Posts

3,623

Location

wickford essex

• Mar 23, 2014

• #11

samc88 said:

The brackets BB showed share the same bolts as what bolt the front panel to the chassis

Click to expand...

Front panel only one bolt too chassis, another bodge job i will have to sort.Or are S2 flat valance different to the curved ones.



samc88

Drivels spiritual representative

Posts

2,838

Location

Anglesey, North Wales

• Mar 23, 2014

• #12

wickford90 said:

Front panel only one bolt too chassis, another bodge job i will have to sort.Or are S2 flat valance different to the curved ones.

Click to expand...

Should be 3 I think unles its different mounting to a series 3. One in the middle and 1 either side
