Hoping for a bit of advice here, just bought a td5 on a 52 plate, drove it home about 80 miles last Saturday, everything seemed great, never moved it until today, as it was cold I swithched the heaters onto hi on both sides, to be greated, with cold air only, water in header tank is fine, levels are spot on, checked the control flaps they are working, matrix pipes coming into the car were just Luke warm, bleed the system to check for air lock, now I'm puzzled, temp gauge sitting at half way on a good run ! Any ideas ? Thanks
2002 td5 heater blowing cold air only
- Thread starter vizlauk
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
Possibly a faulty thermostat, if all else looks normal.
Fingers crossed ! Need the heaters working in this weather, going strip it off tomorrow and try a new thermostat, cheers for your reply.
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
are the 2 heater pipes getting hot on the rhs of bulkhead
Hi, no the 2 heater pipes are Luke warm chances are the heat off the engine is just warming them up !
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
Can't remember if it's been asked, but have you checked/bled the coolant circuit, as it sounds like the fluid is not being circulated.
Also, if you intend to buy another water pump make sure it is an OE one, Quinton Hazel. Ebay sells them for about £42 inc vat.
Dave
Dave , coolest circuit has been bleed / checked, dropped all the coolest out & refilled, it does not seem to be circulating ! Even when engine is up to normal temp the top hose from the rad is hot & under pressure - yet the heater pipes are still cool !
biggeeeee
Retired - Living the dream
- Posts
- 11,090
- Location
- Lanarkshire or Argyll
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
Hi Biggeeee, you do know that you've posted the bleed/refill instructions for the V8 engine don't you?
Dave
Dave
biggeeeee
Retired - Living the dream
- Posts
- 11,090
- Location
- Lanarkshire or Argyll
Attachments
biggeeeee
Retired - Living the dream
- Posts
- 11,090
- Location
- Lanarkshire or Argyll
Think they have just used the wrong picture in RAVE
jamesmartin
Well-Known Member
- Posts
- 91,879
- Location
- louth lincs
a td5 shouldnt be difficult to fill and isnt prone for air lock if filled with bleed screw out and level checked the same way ,coolant in expansion tank doesnt mean engines full
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
I agree.
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
It's all stripped down & new water pump is ready to go in , in the morning, worst part of stripping it down was removing the oil filter ! Regards Sean
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
How have you done it? Removed the whole mounting assembly or removed the rotor filter, to get access to the back of the pump cover?
Removed the aircon & the rotor filter housing unit, it's still a tight squeeze to get the pump out !
thebiglad
Well-Known Member
- Posts
- 7,387
- Location
- Central France
I've got the ACE and aircon pumps loose ready to set aside as I've been mucking around to change the pas pump, so I think I'll remove the pump mounting assembly and leave the rotor filter in place.
That way I can fit the new pump on the bench, then re-install into the car.
Dave
That way I can fit the new pump on the bench, then re-install into the car.
Dave
