Off 'n on!!!!
You're never grateful for the little presents I like to send you, are you?I fink your clouds have got losted and have turned up here. Come gettem willya?
I whistled them and told them to go on to someone else.Am well, thank you kindly @Land_girl
Bit of a burned bonce but that's my own fault
@derwendolly , clouds have wandered off of their accord
Just got to get shot of the house guests and can enjoy the rest of the day..
Blasted tow bar wiggly amps has me in a pickle. Cannot find any info on the loom I have
Wotcha trying to do wiv it?
Is it a branded harness wivs a tow bar doo dat ?
If it's a red, yellow, blue, brown, green, black and a white wire and you got to stick a purple, black, red/orange, red/yellow, red/black, green/white, green/red, green/brown and green/purple wire combo on it ... that's different ....
doriz
Well-Known Member
The loom has red/black green/white red/yellow red/green for example no sign of a purple
Ok,
These are the vehicles wiring colour codes NOT the 7 core trailer wire...
I think for your vehicle ...
plain purple is 12v permanent live feed
red/orange = RH tail light
red/yellow = rear fog light
red/black = LH tail light & rear number plate light
green/white = RH indicator
green/red = LH indicator
green/brown = feed from reverse switch to reverse lights
green/purple = brake light L & R.
the trailer socket pins are numbered as noted in diagram ,view from the face the wires fit into, not where the trailer plug pushes in... so from the BACK of the socket
the 12N trailer socket should have the plain colour wires which go up inside the vehicle & connect into the parent vehicles wiring loom usually in the right rear corner...
leave the purple unconnected but ensure it cannot short out on any metal. with a suitable fuse you can use it as a power feed in the rear...
the 12N trailer socket should have the plain colour wires which go up inside the vehicle & connect into the parent vehicles wiring loom usually in the right rear corner...
leave the purple unconnected but ensure it cannot short out on any metal. with a suitable fuse you can use it as a power feed in the rear...
Is this the towing loom you've bought or the trailer socket loom on your vehicle, (which is ? by the way) ?....
You're never grateful for the little presents I like to send you, are you?
Achooly you're right. I looked like a swan vesta las nite.
Twas indeed a thoughtful act on your part.
http://ktre.nl/download/land-rover-defender-tow-bar-wiring-diagram
Your colours depend on the year of vehicle and model ...
Land_girl
Well-Known Member
6!!!!
