Thank you. I have these 5 relays under the fuse panel, can’t for the life of me figure out what they’re for. A couple appear to just have jumpers connected just so they flow current. One has the big gauge brown wire (hot all the time) feeding it with an equally large wire (white with a red tracer) coming out of it. Another one has smaller wires, and the third has even smaller wires.
This thing is intermittently working some of the lights. I put the marker lights on and no front markers, only rear and license plate light. One more click for the dipped beam, nothing. I had one working a couple days ago but now it’s not. I did get the rear fog light working and found out that only works when the headlights are on. The main beams work fine. Horn works. Blower fan works (but only on high speed). Hazard lights work. When I put the turn signals on, all light flash as if I had the hazard lights on. Happens either left or right side. They DID work normal a couple months ago.
I’m thinking about replacing the fuse blocks with a more modern blade style set up (although I did replace all the round glass fuses with new ones), or just putting in a new wiring harness. Probably a universal kit made for a hot rod from Painless Wiring. I’m not sure yet. I’ll post pics of these relays that I’m not sure what they do in a bit.
