My son has just bought a 2004 TD4 freelander, 80K with service history. I had noticed a small oil leak from one of the intercooler hoses so, after reading alot on here about the EGR, I decided to take a look. Took everything apart and was horrified to see so much oily gunk in all the pipes :
![IMG_0612.jpg IMG_0612.jpg](https://www.landyzone.co.uk/data/attachments/40/40552-38d587a46828256dc5e501140a1d6abd.jpg)
![IMG_0616.jpg IMG_0616.jpg](https://www.landyzone.co.uk/data/attachments/40/40553-5eec10dfbbe93c6908383585d5e3d935.jpg)
![IMG_0617.jpg IMG_0617.jpg](https://www.landyzone.co.uk/data/attachments/40/40554-c1cabf936b438dd20383c5500b10f063.jpg)
![IMG_0619.jpg IMG_0619.jpg](https://www.landyzone.co.uk/data/attachments/40/40555-4c4e4cf01524475ebb120d4f235fbb94.jpg)
![IMG_0620.jpg IMG_0620.jpg](https://www.landyzone.co.uk/data/attachments/40/40556-efe011ad6cd40e937e7a019e3a611322.jpg)
My son has just bought a 2004 TD4 freelander, 80K with service history. I had noticed a small oil leak from one of the intercooler hoses so, after reading alot on here about the EGR, I decided to take a look. Took everything apart and was horrified to see so much oily gunk in all the pipes :
![IMG_0612.jpg IMG_0612.jpg](https://www.landyzone.co.uk/data/attachments/40/40552-38d587a46828256dc5e501140a1d6abd.jpg)
![IMG_0616.jpg IMG_0616.jpg](https://www.landyzone.co.uk/data/attachments/40/40553-5eec10dfbbe93c6908383585d5e3d935.jpg)
![IMG_0617.jpg IMG_0617.jpg](https://www.landyzone.co.uk/data/attachments/40/40554-c1cabf936b438dd20383c5500b10f063.jpg)
![IMG_0619.jpg IMG_0619.jpg](https://www.landyzone.co.uk/data/attachments/40/40555-4c4e4cf01524475ebb120d4f235fbb94.jpg)
![IMG_0620.jpg IMG_0620.jpg](https://www.landyzone.co.uk/data/attachments/40/40556-efe011ad6cd40e937e7a019e3a611322.jpg)
Is this normal ? I am particularly concerned to find oil (albeit less and cleaner) in the turbo pipe coming up from behind the engine (the rigid one). I will replace the crank case breather filter as soon as I can get one - is there anything else I should be looking at/concerned with ? Car runs fine - smoked a little when I had put it all back together but I am assuming that was because I had disturbed everything, but that has cleared.
Any help greatly appreciated.
