Is there a test i can do to check if it is the pump
Using a pressure gauge in the end of the ramp injection
RAVE......
Check
1. Disconnect battery earth lead.
2. Position absorbent cloth beneath fuel pipe to
catch spillage.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.
3. Disconnect fuel pipe from inlet manifold.
4. Connect adaptor LRT-19-010 to LRT-19-004
pressure gauge.
5. Connect adaptor LRT-19-010 and pressure
gauge LRT-19-004 to manifold and fuel pipe.
6. Connect battery earth lead.
7. Start engine. Pressure at idle = 3.5 bar ± 0.2
bar.
8. Release clip, disconnect and plug fuel pressure
regulator vacuum hose.
9. Start engine. Pressure at idle = 3.0 bar ± 0.2
bar.
10. Stop engine. If pressure is out of tolerance
suspect the following in order: fuel hoses,
regulator, filter and pump.
11. Remove plug, reconnect vacuum hose and
secure hose with clip.
12. Disconnect battery earth lead.
13. Disconnect pressure gauge LRT-19-004 and
adaptor LRT-19-010 from fuel pipe and
manifold.
14. Disconnect adaptor LRT-19-010 from LRT-19-004
pressure gauge.
15. Connect fuel pipe to manifold.
16. Connect battery earth lead.
LRT - 19 -004
LRT - 19 -010
M19 3320
