my home made snorkel
- Thread starter mark-d
- Start date
This site contains affiliate links for which LandyZone may be compensated if you make a purchase.
buckshot
Well-Known Member
- Posts
- 9,841
- Location
- right yer!
well i had just backed a trailer into the corner of the field (bit damp in the corner)
Garth of the west
New Member
- Posts
- 36
Any pics of how it's plumbed in under the bonnet?
mark-d
Well-Known Member
- Posts
- 1,107
- Location
- Netherlands
will get some
That'd be good as I quite like this one, also how have you sealed it at the wing/s entry point?
Thin_trucker
Active Member
- Posts
- 317
- Location
- lincoln
I reckon buckshot should do a matching one the other side for the exhaust with a little rain flappy thing on top!
mark-d
Well-Known Member
- Posts
- 1,107
- Location
- Netherlands
ReadySalted
Active Member
- Posts
- 444
I like the idea of this. It's certainly a damn sight cheaper than buying one.
I like the look of mantec ones best, like the ones on the old camel discos. Anyone know what diameter pipe they use? It looks quite think to me, but don't want to choke the engine?
Also, can somebody confirm it's simply a case of; snorkel top attatched to pipe running down A pillar, then into the vehicle, into the airbox, and then sealing up the airbox? Or am I missing something?
I'm thinking of getting southdown snorkel top, and the moulded plastic bit that goes into the wing, a bit of the correct size pipe, and flexi for inside the wing, seal it all together and it shouldn't set me back for more than £40-50. Jobs a good one.
I like the look of mantec ones best, like the ones on the old camel discos. Anyone know what diameter pipe they use? It looks quite think to me, but don't want to choke the engine?
Also, can somebody confirm it's simply a case of; snorkel top attatched to pipe running down A pillar, then into the vehicle, into the airbox, and then sealing up the airbox? Or am I missing something?
I'm thinking of getting southdown snorkel top, and the moulded plastic bit that goes into the wing, a bit of the correct size pipe, and flexi for inside the wing, seal it all together and it shouldn't set me back for more than £40-50. Jobs a good one.
sam1989
New Member
- Posts
- 94
- Location
- worle (weston-super-mare)
hi all i also am thinking of a custom snorkel but the problem i have is the previous owner removed the air box and fitted a cone filter straight onto the pipe from the turbo so do i: do a home made snorkel down through the body onto a pipe running to the turbo, and put a cone filter on the top?????
any advise would be brill!
cheers
any advise would be brill!
cheers
Paulmitchell1984
Well-Known Member
- Posts
- 1,819
- Location
- Leeds
why not just buy a 300tdi or 200tdi air filter and plumb it through that?
sam1989
New Member
- Posts
- 94
- Location
- worle (weston-super-mare)
just didnt know if could run a sutible pipe straight to turbo like it is at the mo????
disco147
Well-Known Member
- Posts
- 1,147
- Location
- Chichester, West Sussex
If you do a search this was asked a few weeks ago...
But the answer is no not really... without a filter you risk dragging crud into the air intake system and with a filter on top if it rains it'll get wet, act a bit like a sponge and hold water then the engine will suck the water into itself, which kinda defies the point of having a snorkel!
Get down the breakers and get a second hand air box from there!
But the answer is no not really... without a filter you risk dragging crud into the air intake system and with a filter on top if it rains it'll get wet, act a bit like a sponge and hold water then the engine will suck the water into itself, which kinda defies the point of having a snorkel!
Get down the breakers and get a second hand air box from there!
sam1989
New Member
- Posts
- 94
- Location
- worle (weston-super-mare)
many thanks for your reply, i should have done a search yes but thought i would ask on this topic as it along the same lines.
so i get an airbox,
make snorkel
put new filter in the airbox and job done?
cheers
